transformers: Out of Memory (OOM) when repeatedly running large models

❓ Any advice for freeing up GPU memory after training a large model (e.g., roberta-large)?

System Info

Platform Linux-4.4.0-1096-aws-x86_64-with-debian-stretch-sid
Python 3.6.6 |Anaconda, Inc.| (default, Jun 28 2018, 17:14:51)
[GCC 7.2.0]
PyTorch 1.3.0
AWS EC2 p3.2xlarge (single GPU)

My current objective is to run roberta-large multiple training jobs sequentially from the same python script (i.e., for a simple HPO search). Even after deleting all of the objects and clearing the cuda cache after the first training job ends I am still stuck with 41% GPU memory usage (as compared to 15% before starting the training process).

I am attaching a reproducible example to get the error:

Here is the relevant code

show_gpu('Initial GPU memory usage:')
for i in range(2):
    model, optimizer, scheduler = get_training_obj(params)
    show_gpu(f'{i}: GPU memory usage after loading training objects:')
    for epoch in range(1):
        epoch_start = time.time()
        model.train()
        for batch in dp.train_dataloader:
            xb,mb,_,yb = tuple(t.to(params['device']) for t in batch)
            outputs = model(input_ids = xb, attention_mask = mb, labels = yb)
            loss = outputs[0]
            loss.backward()
            optimizer.step()
            scheduler.step()
            optimizer.zero_grad()
    show_gpu(f'{i}: GPU memory usage after training model:')
    del model, optimizer, scheduler, loss, outputs
    torch.cuda.empty_cache()
    torch.cuda.synchronize()
    show_gpu(f'{i}: GPU memory usage after clearing cache:')

Here is the output and full traceback

Initial GPU memory usage: 0.0% (0 out of 16130)

0: GPU memory usage after loading training objects: 14.7% (2377 out of 16130)

0: GPU memory usage after training model: 70.8% (11415 out of 16130)

0: GPU memory usage after clearing cache: 41.8% (6741 out of 16130)

1: GPU memory usage after loading training objects: 50.2% (8093 out of 16130)
---------------------------------------------------------------------------
RuntimeError                              Traceback (most recent call last)
<ipython-input-7-20a3bdec1bf4> in <module>()
      8         for batch in dp.train_dataloader:
      9             xb,mb,_,yb = tuple(t.to(params['device']) for t in batch)
---> 10             outputs = model(input_ids = xb, attention_mask = mb, labels = yb)
     11             loss = outputs[0]
     12             loss.backward()

~/anaconda3/lib/python3.6/site-packages/torch/nn/modules/module.py in __call__(self, *input, **kwargs)
    539             result = self._slow_forward(*input, **kwargs)
    540         else:
--> 541             result = self.forward(*input, **kwargs)
    542         for hook in self._forward_hooks.values():
    543             hook_result = hook(self, input, result)

~/anaconda3/lib/python3.6/site-packages/transformers/modeling_roberta.py in forward(self, input_ids, attention_mask, token_type_ids, position_ids, head_mask, labels)
    326                                token_type_ids=token_type_ids,
    327                                position_ids=position_ids,
--> 328                                head_mask=head_mask)
    329         sequence_output = outputs[0]
    330         logits = self.classifier(sequence_output)

~/anaconda3/lib/python3.6/site-packages/torch/nn/modules/module.py in __call__(self, *input, **kwargs)
    539             result = self._slow_forward(*input, **kwargs)
    540         else:
--> 541             result = self.forward(*input, **kwargs)
    542         for hook in self._forward_hooks.values():
    543             hook_result = hook(self, input, result)

~/anaconda3/lib/python3.6/site-packages/transformers/modeling_roberta.py in forward(self, input_ids, attention_mask, token_type_ids, position_ids, head_mask)
    179                                                  token_type_ids=token_type_ids,
    180                                                  position_ids=position_ids,
--> 181                                                  head_mask=head_mask)
    182
    183

~/anaconda3/lib/python3.6/site-packages/transformers/modeling_bert.py in forward(self, input_ids, attention_mask, token_type_ids, position_ids, head_mask)
    625         encoder_outputs = self.encoder(embedding_output,
    626                                        extended_attention_mask,
--> 627                                        head_mask=head_mask)
    628         sequence_output = encoder_outputs[0]
    629         pooled_output = self.pooler(sequence_output)

~/anaconda3/lib/python3.6/site-packages/torch/nn/modules/module.py in __call__(self, *input, **kwargs)
    539             result = self._slow_forward(*input, **kwargs)
    540         else:
--> 541             result = self.forward(*input, **kwargs)
    542         for hook in self._forward_hooks.values():
    543             hook_result = hook(self, input, result)

~/anaconda3/lib/python3.6/site-packages/transformers/modeling_bert.py in forward(self, hidden_states, attention_mask, head_mask)
    346                 all_hidden_states = all_hidden_states + (hidden_states,)
    347
--> 348             layer_outputs = layer_module(hidden_states, attention_mask, head_mask[i])
    349             hidden_states = layer_outputs[0]
    350

~/anaconda3/lib/python3.6/site-packages/torch/nn/modules/module.py in __call__(self, *input, **kwargs)
    539             result = self._slow_forward(*input, **kwargs)
    540         else:
--> 541             result = self.forward(*input, **kwargs)
    542         for hook in self._forward_hooks.values():
    543             hook_result = hook(self, input, result)

~/anaconda3/lib/python3.6/site-packages/transformers/modeling_bert.py in forward(self, hidden_states, attention_mask, head_mask)
    326         attention_outputs = self.attention(hidden_states, attention_mask, head_mask)
    327         attention_output = attention_outputs[0]
--> 328         intermediate_output = self.intermediate(attention_output)
    329         layer_output = self.output(intermediate_output, attention_output)
    330         outputs = (layer_output,) + attention_outputs[1:]  # add attentions if we output them

~/anaconda3/lib/python3.6/site-packages/torch/nn/modules/module.py in __call__(self, *input, **kwargs)
    539             result = self._slow_forward(*input, **kwargs)
    540         else:
--> 541             result = self.forward(*input, **kwargs)
    542         for hook in self._forward_hooks.values():
    543             hook_result = hook(self, input, result)

~/anaconda3/lib/python3.6/site-packages/transformers/modeling_bert.py in forward(self, hidden_states)
    298     def forward(self, hidden_states):
    299         hidden_states = self.dense(hidden_states)
--> 300         hidden_states = self.intermediate_act_fn(hidden_states)
    301         return hidden_states
    302

~/anaconda3/lib/python3.6/site-packages/transformers/modeling_bert.py in gelu(x)
    126         Also see https://arxiv.org/abs/1606.08415
    127     """
--> 128     return x * 0.5 * (1.0 + torch.erf(x / math.sqrt(2.0)))
    129
    130 def gelu_new(x):

RuntimeError: CUDA out of memory. Tried to allocate 26.00 MiB (GPU 0; 15.75 GiB total capacity; 14.24 GiB already allocated; 8.88 MiB free; 476.01 MiB cached)

Appendix / complete code to reproduce

import platform; print("Platform", platform.platform())
import sys; print("Python", sys.version)
import torch; print("PyTorch", torch.__version__)

from __future__ import absolute_import, division, print_function
import glob
import logging
import os
import time
import json
import random
import numpy as np
import pandas as pd
from random import sample, seed
import torch
from torch.utils.data import DataLoader, RandomSampler, SequentialSampler,TensorDataset
from torch.utils.data.distributed import DistributedSampler
from transformers import RobertaConfig, RobertaForSequenceClassification, RobertaTokenizer
from transformers import DistilBertConfig, DistilBertForSequenceClassification, DistilBertTokenizer
from transformers import BertConfig, BertForSequenceClassification, BertTokenizer
from transformers import AdamW, WarmupLinearSchedule
from transformers import glue_compute_metrics as compute_metrics
from transformers import glue_output_modes as output_modes
from transformers import glue_processors as processors
from transformers import glue_convert_examples_to_features as convert_examples_to_features
import subprocess

params = {
    'num_epochs': 2,
    'warmup_ratio': 0.06,
    'weight_decay': 0.1,
    'adam_epsilon': 1e-6,
    'model_name': 'roberta-large',
    'max_grad_norm': 1.0,
    'lr': 2e-5,
    'bs': 32,
    'device': 'cuda',
    'task': 'cola',
    'data_dir': '/home/ubuntu/glue_data/CoLA',
    'max_seq_length': 50,
    'metric_name': 'mcc',
    'patience': 3,
    'seed': 935,
    'n': -1,
      }


class DataProcessor():
    '''Preprocess the data, store data loaders and tokenizer'''

    _TOKEN_TYPES = {
        'roberta': RobertaTokenizer,
        'distilbert': DistilBertTokenizer,
        'bert': BertTokenizer,
    }

    def __init__(self, params):
        model_type = params['model_name'].split('-')[0]
        assert model_type in self._TOKEN_TYPES.keys()
        self.tok = self._TOKEN_TYPES[model_type]
        self.params = params
        self.processor = processors[self.params['task']]()
        self.output_mode = output_modes[self.params['task']]
        self.label_list = self.processor.get_labels()

    @staticmethod
    def _convert_to_tensors(features):
        all_input_ids = torch.tensor([f.input_ids for f in features], dtype=torch.long)
        all_attention_mask = torch.tensor([f.attention_mask for f in features], dtype=torch.long)
        all_token_type_ids = torch.tensor([f.token_type_ids for f in features], dtype=torch.long)
        all_labels = torch.tensor([f.label for f in features], dtype=torch.long)
        return TensorDataset(all_input_ids, all_attention_mask, all_token_type_ids, all_labels)

    def _load_examples(self, tokenizer, evaluate):
        if evaluate:
            examples = self.processor.get_dev_examples(self.params['data_dir'])
        else:
            examples = self.processor.get_train_examples(self.params['data_dir'])
            if self.params['n'] >= 0:
                examples = sample(examples, self.params['n'])
        features = convert_examples_to_features(examples,
                                                tokenizer,
                                                label_list=self.label_list,
                                                max_length=self.params['max_seq_length'],
                                                output_mode=self.output_mode,
                                                pad_on_left=False,
                                                pad_token=tokenizer.convert_tokens_to_ids([tokenizer.pad_token])[0],
                                                pad_token_segment_id=0)

        return self._convert_to_tensors(features)

    def _define_tokenizer(self):
        return self.tok.from_pretrained(self.params['model_name'], do_lower_case=True)

    def load_data(self):
        tokenizer = self._define_tokenizer()
        self.train_data = self._load_examples(tokenizer, False)
        self.valid_data = self._load_examples(tokenizer, True)
        self.train_n = len(self.train_data)
        self.valid_n = len(self.valid_data)
        self.params['total_steps'] = self.params['num_epochs'] * self.train_n
        return self.params

    def create_loaders(self):
        self.train_dataloader = DataLoader(self.train_data, shuffle=True, batch_size=self.params['bs'])
        self.valid_dataloader = DataLoader(self.valid_data, shuffle=False, batch_size=2*self.params['bs'])

dp = DataProcessor(params)
params = dp.load_data()
dp.create_loaders()


def show_gpu(msg):
    """
    ref: https://discuss.pytorch.org/t/access-gpu-memory-usage-in-pytorch/3192/4
    """
    def query(field):
        return(subprocess.check_output(
            ['nvidia-smi', f'--query-gpu={field}',
                '--format=csv,nounits,noheader'],
            encoding='utf-8'))
    def to_int(result):
        return int(result.strip().split('\n')[0])

    used = to_int(query('memory.used'))
    total = to_int(query('memory.total'))
    pct = used/total
    print('\n' + msg, f'{100*pct:2.1f}% ({used} out of {total})')


# ### Running the Training Loop

def get_training_obj(params):
    config = RobertaConfig.from_pretrained(params['model_name'], num_labels=2)
    model = RobertaForSequenceClassification.from_pretrained(params['model_name'], config=config).to(params['device'])
    no_decay = ['bias', 'LayerNorm.weight']
    gpd_params = [
        {'params': [p for n, p in model.named_parameters() if not any(nd in n for nd in no_decay)],
         'weight_decay': params['weight_decay']},
        {'params': [p for n, p in model.named_parameters() if any(nd in n for nd in no_decay)],
         'weight_decay': 0.0}
        ]
    optimizer = AdamW(gpd_params, lr=params['lr'], eps=params['adam_epsilon'])
    warmup_steps = int(params['warmup_ratio'] * params['total_steps'])
    scheduler = WarmupLinearSchedule(optimizer, warmup_steps=warmup_steps, t_total=params['total_steps'])
    return model, optimizer, scheduler


show_gpu('Initial GPU memory usage:')
for i in range(2):
    model, optimizer, scheduler = get_training_obj(params)
    show_gpu(f'{i}: GPU memory usage after loading training objects:')
    for epoch in range(1):
        epoch_start = time.time()
        model.train()
        for batch in dp.train_dataloader:
            xb,mb,_,yb = tuple(t.to(params['device']) for t in batch)
            outputs = model(input_ids = xb, attention_mask = mb, labels = yb)
            loss = outputs[0]
            loss.backward()
            optimizer.step()
            scheduler.step()
            optimizer.zero_grad()
    show_gpu(f'{i}: GPU memory usage after training model:')
    del model, optimizer, scheduler, loss, outputs
    torch.cuda.empty_cache()
    torch.cuda.synchronize()
    show_gpu(f'{i}: GPU memory usage after clearing cache:')
