rancher: Unable to set up Rancher Keycloak SAML auth

Hi there,

Rancher versions: rancher/rancher:latest (v2.1)

Infrastructure Stack versions: kubernetes: 1.10.7_1521

Docker version:

Server Version: 18.03.1-ce
Storage Driver: overlay2
 Backing Filesystem: extfs
 Supports d_type: true
 Native Overlay Diff: true
Logging Driver: json-file
Cgroup Driver: cgroupfs
Swarm: inactive
Runtimes: runc
Default Runtime: runc
Init Binary: docker-init
containerd version: 773c489c9c1b21a6d78b5c538cd395416ec50f88
runc version: 4fc53a81fb7c994640722ac585fa9ca548971871
init version: 949e6fa
Kernel Version: 3.10.0-693.21.1.el7.x86_64
Operating System: CentOS Linux 7 (Core)

Operating system and kernel: (cat /etc/os-release, uname -r preferred) Ref to Docker info above

Type/provider of hosts: (VirtualBox/Bare-metal/AWS/GCE/DO) Other (Virtual Server)

Setup details: (single node rancher vs. HA rancher, internal DB vs. external DB) Single node, internal DB

Environment Template: (Cattle/Kubernetes/Swarm/Mesos) k8s

Steps to Reproduce: Go to https://<your_rancher_url>/g/security/authentication/keycloak Fill the form according to https://rancher.com/docs/rancher/v2.x/en/admin-settings/authentication/keycloak/

My setup:

• Display Name Field = cn
• User Name Field = givenname
• UID Field = uid
• Groups Field = memberof
• Rancher API Host = https://<my_rancher_url>
• And private key + cert + Metada xml from Keycloak Then click on “Authenticate with Keycloak”

Expected Results: As suggested by Rancher, you should be redirected to Keycloak’s login page (pop-up)

Actual Results: A new window pops up, however you are not redirected to Keycloak’s login page but end up on the same URL https://<my_rancher_url>/g/security/authentication/keycloak?RelayState=<really_long_saml_stuff>

Additional observations. Few things I noticed:

1. The SAML request is never sent to my keycloak server
2. If I compare the SAML GET request from Rancher to a valid SAML GET request from another app, I can see there is no “Destination” attribute in the AuthnRequest tag

<?xml version="1.0" encoding="UTF-8"?>
<samlp:AuthnRequest xmlns:samlp="urn:oasis:names:tc:SAML:2.0:protocol" xmlns:saml="urn:oasis:names:tc:SAML:2.0:assertion" ID="id-60618df5801f187f14af8922069e14379b4a3c52" Version="2.0" IssueInstant="2018-10-08T16:09:14.257Z" AssertionConsumerServiceURL="https://my_rancher_url/v1-saml/keycloak/saml/acs" ProtocolBinding="urn:oasis:names:tc:SAML:2.0:bindings:HTTP-POST">
   <saml:Issuer Format="urn:oasis:names:tc:SAML:2.0:nameid-format:entity">https://my_rancher_url/v1-saml/keycloak/saml/metadata</saml:Issuer>
   <samlp:NameIDPolicy Format="urn:oasis:names:tc:SAML:2.0:nameid-format:transient" AllowCreate="true" />
</samlp:AuthnRequest>

Which might explain 1. 3. If I compare this request to another valid request, I can see the missing “Destination” attribute

<?xml version="1.0" encoding="UTF-8"?>
<samlp:AuthnRequest xmlns:samlp="urn:oasis:names:tc:SAML:2.0:protocol" xmlns:saml="urn:oasis:names:tc:SAML:2.0:assertion" AssertionConsumerServiceURL="myACS_URL" Destination="https://my_keycloak/auth/realms/my_realm/protocol/saml" ID="_4a3d5f17-d8c6-41e5-8393-d5b6e03a73e5" IssueInstant="2018-10-08T16:10:35Z" Version="2.0">
   <saml:Issuer>my_issuer</saml:Issuer>
   <samlp:NameIDPolicy AllowCreate="true" Format="urn:oasis:names:tc:SAML:1.1:nameid-format:emailAddress" />
</samlp:AuthnRequest>

1. Contrary to all application for which I set up a SAML auth with Keycloak, I did not provide the “Identity provider SSO URL” to Rancher, even if this information is available in the metadata.xml file provided to Rancher. For ref, the metadata.xml I provided:

<?xml version="1.0" encoding="UTF-8"?>
<EntityDescriptor entityID="https://mykeycloak/auth/realms/my_realm"
                   xmlns="urn:oasis:names:tc:SAML:2.0:metadata"
                   xmlns:dsig="http://www.w3.org/2000/09/xmldsig#"
                   xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">
   <IDPSSODescriptor WantAuthnRequestsSigned="true"
      protocolSupportEnumeration="urn:oasis:names:tc:SAML:2.0:protocol">
      <SingleLogoutService
         Binding="urn:oasis:names:tc:SAML:2.0:bindings:HTTP-POST"
         Location="https://mykeycloak/auth/realms/my_realm/protocol/saml" />
   <NameIDFormat>urn:oasis:names:tc:SAML:2.0:nameid-format:persistent</NameIDFormat>
   <NameIDFormat>urn:oasis:names:tc:SAML:2.0:nameid-format:transient</NameIDFormat>
   <NameIDFormat>urn:oasis:names:tc:SAML:1.1:nameid-format:unspecified</NameIDFormat>
   <NameIDFormat>urn:oasis:names:tc:SAML:1.1:nameid-format:emailAddress</NameIDFormat>

      <SingleSignOnService Binding="urn:oasis:names:tc:SAML:2.0:bindings:HTTP-POST"
         Location="https://mykeycloak/auth/realms/my_realm/protocol/saml" />
      <KeyDescriptor use="signing">
        <dsig:KeyInfo>
          <dsig:KeyName>key_name</dsig:KeyName>
          <dsig:X509Data>
            <dsig:X509Certificate>my_cert</dsig:X509Certificate>
          </dsig:X509Data>
        </dsig:KeyInfo>
      </KeyDescriptor>
   </IDPSSODescriptor>
</EntityDescriptor>

Maybe that’s just a configuration issue on my side. I’ll gladly submit a PR on Rancher documentation regarding Keycloak conf when I figure this out.
