vscode-jupyter: Local vs Remote is not obvious

Applies To

• Notebooks (.ipynb files)
• Interactive Window and/or Cell Scripts (.py files with #%% markers)

What happened?

Hi bros,

I got a issue, steps to reproduce as below:

• Install jupyterlab as tutorial https://research.google.com/colaboratory/local-runtimes.html#:~:text=In Colaboratory%2C click the "Connect,connected to your local runtime.
• Copy uri after starting jupyter server (http://localhost:8888/?token=a96d38b9077b2c7cfd05d4e255286febcb4bbaf0c5f86f27)
• Install Jupyter extension on vscode
• Connect colab runtime to local jupyter server:
  • Click connect https://gyazo.com/dcd8e4636361213a24dc56e1481efacf
  • Paste uri link that copied https://gyazo.com/53c9edd93f92abbb48fcc39847f21016
• Connect vscode to local jupyter server:
  • Open vscode -> Ctrl + Shift + P -> Jupyter: Specify Jupyter Server for Connections -> Existing -> paste uri link that copied
  • URL (http://localhost:8888/?token=a96d38b9077b2c7cfd05d4e255286febcb4bbaf0c5f86f27)

Result: Colab connect runtime to local jupyter server successfully. Vscode can’t connect local jupyter server.

Thanks in advanced for your help!

VS Code Version

1.68.1(user setup)

Jupyter Extension Version

v2022.6.1001631011

Jupyter logs

info 22:43:52.812: Creating server with url : http://localhost:8888/
info 22:43:53.3: Checking for server existence.
info 22:43:53.8: Checking for server usability.
info 22:43:53.8: Starting notebook server.
info 22:43:53.9: Connecting to server
info 22:43:53.11: Connecting to process server
info 22:43:53.11: Connecting server kernel http://localhost:8888/
Connecting to Jupyter server at http://localhost:8888/
info 22:43:53.11: Creating server with url : http://localhost:8888/
info 22:43:53.16: Connection complete server
info 22:43:53.18: Server started.
info 22:43:53.18: Creating server with url : http://localhost:8888/
info 22:43:53.169: Creating server with url : http://localhost:8888/
info 22:44:15.867: Loading webview. View is notset
info 22:44:15.869: Loading web view...
info 22:44:15.870: Webview panel created.
info 22:44:16.143: Web view react rendered

Jupyter server logs (Window cmd)

jupyter notebook --NotebookApp.allow_origin='https://colab.research.google.com' --port=8888 --NotebookApp.port_retries=0
jupyter_http_over_ws extension initialized. Listening on /http_over_websocket
[W 2022-06-22 21:49:53.045 LabApp] 'allow_origin' has moved from NotebookApp to ServerApp. This config will be passed to ServerApp. Be sure to update your config before our next release.
[W 2022-06-22 21:49:53.045 LabApp] 'port' has moved from NotebookApp to ServerApp. This config will be passed to ServerApp. Be sure to update your config before our next release.
[W 2022-06-22 21:49:53.045 LabApp] 'port_retries' has moved from NotebookApp to ServerApp. This config will be passed to ServerApp. Be sure to update your config before our next release.
[W 2022-06-22 21:49:53.045 LabApp] 'port_retries' has moved from NotebookApp to ServerApp. This config will be passed to ServerApp. Be sure to update your config before our next release.
[I 2022-06-22 21:49:53.045 LabApp] JupyterLab extension loaded from C:\Users\MSI GAMING\AppData\Local\Programs\Python\Python38\lib\site-packages\jupyterlab
[I 2022-06-22 21:49:53.045 LabApp] JupyterLab application directory is C:\Users\MSI GAMING\AppData\Local\Programs\Python\Python38\share\jupyter\lab
[I 21:49:53.045 NotebookApp] Serving notebooks from local directory: C:\Users\MSI GAMING\.jupyter
[I 21:49:53.045 NotebookApp] Jupyter Notebook 6.4.12 is running at:
[I 21:49:53.045 NotebookApp] http://localhost:8888/?token=0c35085c94c0f1bf98975d9fe8ecdf9662f5a808f5f487da
[I 21:49:53.045 NotebookApp]  or http://127.0.0.1:8888/?token=0c35085c94c0f1bf98975d9fe8ecdf9662f5a808f5f487da
[I 21:49:53.045 NotebookApp] Use Control-C to stop this server and shut down all kernels (twice to skip confirmation).
[C 21:49:53.092 NotebookApp]

    To access the notebook, open this file in a browser:
        file:///C:/Users/MSI%20GAMING/AppData/Roaming/jupyter/runtime/nbserver-8248-open.html
    Or copy and paste one of these URLs:
        http://localhost:8888/?token=0c35085c94c0f1bf98975d9fe8ecdf9662f5a808f5f487da
     or http://127.0.0.1:8888/?token=0c35085c94c0f1bf98975d9fe8ecdf9662f5a808f5f487da
[W 21:50:07.022 NotebookApp] Forbidden
[W 21:50:07.022 NotebookApp] 403 GET /api/kernels?1655909407020 (127.0.0.1) 1.000000ms referer=None
[W 21:50:19.775 NotebookApp] Forbidden
[W 21:50:19.776 NotebookApp] 403 GET /api/kernelspecs?1655909419773 (127.0.0.1) 1.010000ms referer=None
[W 21:50:36.673 NotebookApp] Forbidden
[W 21:50:39.017 NotebookApp] 403 GET /api/sessions?1655909436673 (127.0.0.1) 2344.740000ms referer=None

Coding Language and Runtime Version

Python 3.8.8 64-bit

Language Extension Version (if applicable)

v2022.8.0

Anaconda Version (if applicable)

Pip 22.1.2 instead

Running Jupyter locally or remotely?

Local
